How to install and use small refrigerator

First, the installation and use of the car refrigerator

(1) Installation and use method of energy storage type car refrigerator

The energy storage car refrigerator does not need to be installed, just put it in the car. The method of use is: when it is necessary to refrigerate, first place the energy storage box flat in the household refrigerator or freezer, freeze it for 10 hours, put it in the incubator, and place it on the top or side of food, beverages, fruits, etc. Close the lid tightly, and the temperature of the box can be stabilized at 15°C

The following is about 20 hours; when heating is required, first place the energy storage box flat in the microwave oven for 2 minutes, and then place it flat in the incubator after the temperature rises to 60~70 °C, and place it on the bottom or side of food, beverages, etc. , cover tightly and cover, and the box temperature can be stable above 40 ℃ for about 4 hours.

(2) Installation and use method of semiconductor type car refrigerator

When installing a small semiconductor car refrigerator, just fix it in a suitable position in the car, and then insert the power plug into the cigarette lighter socket. How to use: When cooling is required, turn the cold/heat switch to the cooling block; when heating is required, turn the cold/heat switch to the heating block.

(3) Installation and use method of compressor type car refrigerator

Most compressor-type car refrigerators can be used both in the car and at home. The installation and use methods are as follows.

1. How to install and use in the car

a. For use in the car, the box should be fixed in a suitable position in the car, and good ventilation should be maintained.

b. Put the "AC, DC" switch in the DC gear; select the "cold/hot" switch gear, the corresponding indicator light is on, and the machine starts to work.

c. Insert one end of the DC power cord into the DC jack on the refrigerator, and the other end into the 12V cigarette lighter socket in the car, the current should be greater than 5A.

d. Put the "cooling, heating" switch to the open gear, or put the "AC, DC" switch to the open gear, the machine can stop working.

e. During heating, when the temperature in the box rises to 70°C ± 5°C, the power supply will automatically cut off, and when the temperature is lower than 60°C ± 5°C, the power supply will automatically turn on to continue heating.

Second, the method of home installation and use

a. Insert one end of the AC power cord into the AC jack on the refrigerator and the other end into the 220V AC power socket.

b. Set the "AC, DC" switch to AC gear; select the "Cold/Hot" switch gear, the corresponding indicator light is on, and the machine starts to work.

c. Put the cooling and heating selector switch to the off block, or put the AC and DC transfer switch to the off block, the machine can stop working.

d. During heating, when the temperature in the box rises to 70°C ± 5°C, the power supply will be automatically cut off, and when the temperature is lower than 60°C ± 5°C, the power supply will be automatically turned on to continue heating.

The following matters should be paid attention to when installing and using the small car refrigerator.

a. When the small car refrigerator is used in the car, only 12V DC can be used. ·

b. The ventilation openings and heat dissipation holes should be kept unobstructed.

c. Under the heating working state, the box is suitable for storing heated food, but it is not suitable for storing frozen food.

d. When switching from the heating function, the power should be turned off and restarted after 5 minutes.
